الزامات سخت افزاری مورد نیاز جهت نصب نرم افزار Autodesk inventor 2019
و
الزامات کار با کار با مجموعه های مونتاژی بزرگ در نرم افزار Autodesk inventor 2019
System requirements for Autodesk Inventor 2019
Issue:
This article provides the system requirements for Autodesk® Inventor 2019.
Please make sure that you are installing the appropriate version of Autodesk Inventor software for your operating system. Inventor 2019 is only supported on 64-bit operating systems and cannot be installed on a 32-bit system.
Solution:
System Requirements for Autodesk Inventor 2019 Windows:
Operating System:
- ۶۴-bit Microsoft® Windows® ۱۰ Anniversary Update (version 1607 or higher)
- ۶۴-bit Microsoft Windows 8.1
۶۴-bit Microsoft Windows 7 SP1 with Update KB4019990
CPU:
Recommended:
۳.۰ GHz or greater, 4 or more cores
Minimum:
۲.۵ GHz or greater
Memory:
Recommended:
۲۰ GB RAM or more
Minimum:
۸ GB RAM for less than 500 part assemblies
Disk Space:
Installer plus full installation: 40 GB
Graphics:
Recommended:
۴ GB GPU with 106 GB/S Bandwidth and DirectX 11 compliant
Minimum:
۱ GB GPU with 29 GB/S Bandwidth and DirectX 11 compliant
Display Resolution:
Recommended:
۳۸۴۰ x 2160 (4K); Preferred scaling: 100%, 125%, 150% or 200%
Minimum:
۱۲۸۰ x 1024 (1080p)
Pointing Device:
MS-Mouse compliant (3DConnexion 3D Mouse optional)
Network:
Internet connection for web install with Autodesk® Desktop App, Autodesk® collaboration functionality, .NET installation, web downloads, and licensing.
Network license manager supports Windows Server® ۲۰۱۶, ۲۰۱۲, ۲۰۱۲ R2, 2008 R2 and the operating systems listed above.
Virtualization:
Citrix® XenApp™ ۷.۶, Citrix® XenDesktop™ ۷.۶ (requires Inventor Network Licensing).
For Complex Models, Complex Mold Assemblies, and Large Assemblies (typically more than 1,000 parts):
CPU Type:
Recommended:
۳.۳۰ GHz or greater, 4 or more cores
Memory:
Recommended:
۲۴ GB RAM or greater
Graphics:
Recommended:
۴ GB GPU with 106 GB/S Bandwidth and DirectX 11 compliant
Notes:
- Autodesk® Inventor® is optimized to take advantage of the SSE2 extended instruction sets supported on Pentium 4, AMD Athlon 64, and AMD Opteron processors. Inventor 2019 will not install on computers that do not support SSE2. Several utilities are available on the Internet that report CPUID including supported instructions sets.
